Models 700, 800 Systems
Solid Managment Systems. ESD Waste2Water, Inc offers a system to eliminate large in-ground sumps and drive-in pits saving on space and messy clean outs. The Solids Management System (SMS) is a waste separator designed to handle solids above ground while recycling the wash water. The SMS is designed to process large amounts of sludge and place into an easy to remove Solids Hopper. The models 700 & 800 Systems will reduce operator maintenance for heavy wash applications such as:
The HSMS Series is the latest in wash water recycling technology. The HSMS series is designed to biologically treat heavy equipment washing applications. The integrated Inclined Plate Clarifier combined with the Biological Treatment System creates a low Turbidity water quality. The HSMS provides the versatility to separate suspended solids and hydrocarbons all in one compact wastewater recycling system to produce a high quality recycled wash water. Contact ESD Waste2Water, Inc. to discuss a design today and learn more about the HSMS Advantage.
|SOLIDS MANAGEMENT MODEL||INCLINED PLATE SEPARATOR SURFACE||WASHING STATIONS||MEDIA||DIMENSIONS||OPERATING CAPACITY||ELECTRICAL||FRESH WATER||NET WEIGHT|
|700 Series||277 Square Feet||1||822.5 Square Feet Surface Area||132 1/2″ x 48 1/2 ” x 64 (LxWx H)||622 Gallon||240 Volt, Single Phase, 40 Amp with Neutral Wire||3/4″||Approx 1,500 lbs. Dry|
|800 Series * Water Cannon Option – 20 GPM @ 200PSI||480 Square Feet||1||2,115 Square Feet Surface Area||186″ x 60 1/2 ” x 64 (LxWx H)||1,834 Gallon||240 Volt, Single Phase, 40 Amp with Neutral Wire “80 Amp||3/4″||Approx 2,000 lbs. Dry|
Models 750, 850 & 5000
Industrial Wash Water Recycle Systems. ESD Waste2Water offers a full line of industrial wash water recycle systems designed to supply between one and six pressure washers for washing industrial equipment or parts. For optimal performance, ESD Waste2Water, Inc. will design, at no charge, a wash area for your particular application. The models 750, 850 & 5000 are versatile, require low maintenance and are extremely effective for such wash applications as:
|Specifications||Model 750||Model 850||Model 5000|
|Flow Range:||015 GPM||015 GPM||050 GPM|
|Daily Treatment Capacity:||1,250 gallons||3,030 gallons||6,050 gallons|
|Electrical:||230 Volt 1 Phase 40 amp||230 Volt 1 Phase 40 amp||230 Volt 1 Phase 60 amp|
|Fresh Water Supply:||3/4″ line required||3/4″ line required||3/4″ line required|
|Tank Operating Capacity||598 gallons||1,350 gallons||2,020 gallons|
|Biological Media:||1,152 sq ft||2,679 sq ft||4,320 sq ft|
|Pressure Pump: (Centrifugal)||3/4 hp||3/4 hp||1 hp|
|Regenerative Blower:||1.5 hp||1.5 hp (2)||1.5 hp|
|Dimensions: (L x W x H)||7’6″ x 4′ x 4’3″||10′ x 5′ x 5’3″||16′ x 5′ x 5’3″|
|Net Weight:||450 lbs||1,100 lbs||1,700 lbs|
The GSMS Series is the latest in wash water recycling technology. The GSMS Series is designed for treating Turf Care maintenance facility equipment with up to 4-hose stations. The addition of the Grass Clipping Separator, the integrated Inclined Plate Clarifier combined with the Biological Treatment System creates a water quality with a low Turbidity. The GSMS providers the versatility to separate grass clippings, suspended solids and hydrocarbons all in one compact commercial water recycling system.
Model 750 and 1500
|Specifications||Model 750 – 1 hose water recycling system||Model 1500 – 2 hose water recycling system|
|Flow Range:||015 GPM||015 GPM|
|Daily Treatment Capacity:||1,250 gallons||2,510 gallons|
|Electrical:||230 Volt 1 Phase 40 amp||230 Volt 1 Phase 40 amp|
|Fresh Water Supply:||3/4″ line required||3/4″ line required|
|Tank Operating Capacity||598 gallons||860 gallons|
|Biological Media:||1,152 sq ft||2,304 sq ft|
|Pressure Pump: (Centrifugal)||3/4 hp||1 hp|
|Regenerative Blower:||1.5 hp||1.5 hp|
|Dimensions: (L x W x H)||7′ x 4′ x 4’3″||11′ x 4′ x 4’3″|
|Net Weight:||450 lbs||750 lbs|
ESD Waste2Water Inc.’s next generation Wash Water Treatment System. A combined TWO-PHASE System that is designed to separate the solids in an Incline Plate Clarifier making it easy for the operators to remove the sludge all while the Biological Treatment System consumes the organics (oils, greases, fuel residue, etc.) converting it into carbon dioxide and water. The incredible bi-product of this process is a clear “grey” water.
The ESD Waste2Water, Inc. Combo Unit is ideal for:
Additional advantages for this remarkable breakthrough:
We have created the ultimate in wash rack solids handling. The new ESD Waste2Water, Inc. Solids Management System, or SMS, eliminates traditional, often large, Drive-in Pits or Multiple in ground sump pit systems. Our new Solids Management System has the capability of processing 80 gallons per minute to a pressure washer, while removing heavy solids in a quality closed loop and recycled wash water system. It alleviates the time-consuming handling of sludge and solids out of in-ground pits, while producing a quality of recycled wash water never seen before.
The Wash Rack Operator begins to wash a piece of equipment. While cleaning the heavy solids off of rubberized tired equipment, tracked equipment, undercarriages, buckets, etc., larger heavy solids or rocks are left on the pad for easy removal. Water and sludge flow into a small sump area so a submersible sump pump can lift the sludge thru a static mixer. The water, sludge and heavy solids enter into a mixing tank allowing larger particles to coagulate and settle into a cone-shaped tank. The water continues into an Inclined Plate Clarifier, further allowing the sludge to separate, while the water flows into either a Water Cannon Clarifier or Biological Treatment System.
The coagulated solids are then dispensed daily into an above ground solids hopper. Once filled, the Solids Hopper can either bedumped into a bucket of a frontend loader or moved and dumped via a forklift. The remaining grey water can either then pass thru a high volume wash system water cannon, 80 gallons a minute at 50 psi, or continue to be processed thru a Biological Wash Water Treatment System. The biological system provides oxygen to fixed film bacteria to rapidly degrade organic contaminants like oil, grease, gasoline, diesel fuel, herbicides and pesticides. This creates a clear “grey water” that can then be recycle back through a pressure washer.
